Solid Flat-Bottom Fish Mouth Clamp

Short Description:

Part No. DH9014

Glass Thickness: 6mm
Weight: 0.07Kg
Outline Dimension: 30mm*18mm*33mm
Material: 2205/304/316
Application: Glass Display Case, Glass Fence, Glass Staircase

Product Detail

Product Tags

Glass Clamp Description

This Stainless Steel, Solid Fish Mouth Clamp is designed to securely hold 6mm glass panels in railing systems without the need for drilled holes. Its flat-bottom design enhances stability and ensures a firm grip, while the fish mouth shape allows for straightforward installation.

Crafted from durable stainless steel, the clamp offers excellent load-bearing capacity and is corrosion-resistant, ensuring long-term reliability for both indoor and outdoor applications. This design preserves the structural integrity of the glass, offering a secure, non-invasive mounting solution.

To accommodate various design requirements, the clamp is available in multiple sizes, finishes, and styles, providing flexibility to match different architectural and aesthetic preferences.

Glass Clamp Specifications

Product Name	No Hole Flat Bottom Fish Mouth Clamp
Outline Dimension	30mm18mm33mm
Glass Thickness	6mm
Weight	0.07Kg
Finish	Classic Satin/Mirror Powder Coat Matte Black/White PVD-Black/Gold/Rose Gold/Gun Grey (We can do anti-fingerprint if necessary.) Anti-conductive Black/White Transparent Satin/Mirror
Material	Duplex stainless steel 2205, Stainless steel 304/316
Application	Glass Display Case, Glass Fence, Glass Staircase
Casting Process	Siica Sol Technics With Lost-wax Process
Certifications	Australian Standard Test/Patent Certificate/IATF16949/ISO9001/ISO14001/TUV/PED/AD2000
OEM	Available
Annual Output	2000MT
Tooling Leadtime	2--4 Weeks
Delivery Time	4--5 Weeks
